Mini lathe machine UTL20, UTL20L
Request a Quote
Out of Stock
Main Features:
1. The lathe bed is made of high quality cast iron, after high frequency quenching, precision grinding.
2. All metal gear
3. Gearshift gear torque is convenient
4. 110 v, 220 v, 380 v motor can be arbitrary choice. Ac motor stable and durable
Nationwide
Delivery
Delivery
Pay via
M-Pesa
M-Pesa
100% Genuine
Products
Products
Genuine & Warranted
Sourced from trusted suppliers with manufacturer-backed warranty.
Fast Nationwide Delivery
Countrywide dispatch with reliable courier partners across Kenya.
Expert Support
Talk to our team on WhatsApp for specs, quotes and bulk orders.
Product Description
| Model No. | UTL250/UTL250V | UTL280 /UTL280V |
| Height of centers | 125mm | 140mm |
| Max.swing over bed | 250mm | 280mm |
| Max.swing over crosss slide | 145mm | 165mm |
| Width of bed | 135mm | 180mm |
| Distance between centers | 550/750mm | 700mm |
| Spindle bore | 26mm | 26mm |
| Taper of spindle hole | MT4 | MT4 |
| Number of steps of spindle speeds | 6/variable | 6/variable |
| Range of spindle speeds | 125-2000/50-200RPM | 125-2000/50-200RPM |
| Range of inch threads | 8-56TPI | 8-56TPI |
| Metric thread cutting | 0.4-3.5mm | 0.4-3.5mm |
| Range of cross feeds | ||
| Range of longitudinal feeds | 0.07-0.20mm/rev | 0.07-0.20mm/rev |
| Tailstock quill travel | 70mm | 80mm |
| Travel of cross slide | 115mm | 140mm |
| Taper of tailstock sleeve | MT2 | MT2 |
| Motor | 0.55/0.75KW | 0.75/1.1KW |
| Machine size | 1150/1350x560x570mm | 1400x700x680mm |
| Net weight | 120kg/140KG | 190KG |
