Slotting machine B5020D,B5032D,B5050A,B5063
Request a Quote
Out of Stock
Main features:
1. This machine is used forslotting the flat and formed surface keyways, etc.
2. It is suitable for eithersingle piece of small batch production
3. The main transmission mechanismis used for converting the rotating motion of the crank gear into reciprocatingmotion of rain
4. The worktable Is designed forlongitudinal, cross and rotary feeding both automatically (only for D typemodel) and manually
5. The feed is stoppedautomatically, when the worktable is in case of trouble
Nationwide
Delivery
Delivery
Pay via
M-Pesa
M-Pesa
100% Genuine
Products
Products
Genuine & Warranted
Sourced from trusted suppliers with manufacturer-backed warranty.
Fast Nationwide Delivery
Countrywide dispatch with reliable courier partners across Kenya.
Expert Support
Talk to our team on WhatsApp for specs, quotes and bulk orders.
Product Description
| Specification | B5020D | B5032D | B5040 | BC5050 | B5063 |
| Max slotting length | 200mm | 320mm | 400mm | 500mm | 630mm |
| Max dimensions of workpiece (LxH) | 485x200mm | 600x320mm | 700x320mm | ||
| Max weight of workpice | 400kg | 500kg | 500kg | 2000kg | 2000kg |
| Table diameter | 500mm | 630mm | 710mm | 1000mm | 1120mm |
| Max longitudinal travel of table | 500mm | 630mm | 560/700mm | 1000mm | 1120mm |
| Max cross travel of table | 500mm | 560mm | 480/560mm | 660mm | 800mm |
| Range of table power feeds (mm) | 0.052-0.738 | 0.052-0.738 | 0.052-0.783 | 3,6,9,12,18,36 | 3,6,9,36/16,12,24,29 |
| Main motor power | 3kw | 4kw | 5.5kw | 7.5kw | 10kw |
| Overall dimensions (LxWxH) | 1836x1305x1995mm | 2180x1496x2245mm | 2450x1525x2535mm | 3480x2085x3307mm | 3580x2390x3660mm |
