ZX7550W/ZX7550CW
Request a Quote
Out of Stock
Main features:
1. Uses standardized assemblies from the VH milling machine universal use as milling machines and drill press
2. Easily shiftable gear driveen sures power transmission without losses
3. With V-belt spindle drive andgear spindle drive
4. Head swivels into thehorizontal level on both sided via crank and toothed gear, easy activation of manual micro-feed for the spindle quill
5. Three axis hardened treatment, high rigidity.
6. vertical horizontal multi-functional ,drilling ,milling, boring operation.
7. X axis mechanical feed,Y.Zaxis can be added the device
8.Gear transmission milling head, stable transmission, compact structure ,easy maintenance, easy to operate
Nationwide
Delivery
Delivery
Pay via
M-Pesa
M-Pesa
100% Genuine
Products
Products
Genuine & Warranted
Sourced from trusted suppliers with manufacturer-backed warranty.
Fast Nationwide Delivery
Countrywide dispatch with reliable courier partners across Kenya.
Expert Support
Talk to our team on WhatsApp for specs, quotes and bulk orders.
Product Description
| Model | ZX7550W | ZX7550CW |
| Max.drilling dia (mm) | 50 | 50 |
| Max.horizontal milling dia (mm) | 100 | 100 |
| Max.vertical milling dia (mm) | 25 | 25 |
| Max.boring dia (mm) | 120 | 120 |
| Max.tapping dia | M16(Vertical) | M16 |
| Spindel Tapper | ISO30/R8 | ISO30/R8 |
| Distance.spindle to table surface (mm) | 80-460 | 90-490 |
| Spindle speeds range (r.p.m) | 230-1825(Vertical) 80-1300(horizontal) | (Vertical)115-1750 (Horizontal)60-1350 |
| Spindle travel | 120 | 120 |
| Table size (mm) | 800x240 | 800×240 |
| Table travel (mm) | 400x230 | 400×230 |
| Overall dimensions (mm) | 1280×1100×2080 | 1280×1100×2080 |
| Motor (Kw) | 0.85/1.5(Vertical) 1.1(horizontal) | ( Vertical)0.85/1.5 (horizontal)2.2 |
| N.W/G.W (Kg) | 700/880 | 850/1000 |
